| S.No | Items | Technical Parameter |
|---|---|---|
| 1 | Panel Dimension | 320 x 160 mm |
| 2 | Panel Pixel | 128 * 64 = 8192 Dots |
| 3 | LED | 3 in 1 LED |
| 4 | Dots/m² | 160000 Dots/m² |
| 5 | Max Power Dissipation | ≤6000W/m² |
| S.No | Items | Detailed Parameters |
|---|---|---|
| 6 | Viewing Angle | 130-140 ±10 degree |
| 8 | Display Brightness | 4500~6500 cd/m² |
| 9 | Colors | 4398 Billion |
| 10 | View Distance | ≥3m, Contents Clear Displayed |
| 11 | Operation Environment | Outdoor |
| 12 | Greyscale | 14-16 Bits (RGB each) |
| 13 | Working Temperature & Humidity | -30 ~ +65°C / 10%-90% RH |
| 14 | Planeness | Whole Display: ≤±1mm Splicing |
| 15 | Protection Grade | Back: IP65, Refresh Rate: 1920Hz |
| Specification | 1.25mm | 1.538mm | 1.86mm | 2mm | 2.5mm | 3.076mm |
|---|---|---|---|---|---|---|
| LED Configuration | SMD1010 | SMD1212 | SMD1515 | SMD1515 | SMD2020/2121 | SMD2020/2121 |
| Module Size | 320x160mm | 320x160mm | 320x160mm | 320x160mm | 320x160mm | 192x192mm |
| Module Resolution | 256×128 | 208×104 | 172×86 | 160×80 | 128×64 | 104×52 |
| Pixel Density | 640000dots/m² | 422755dots/m² | 289050dots/m² | 250000dots/m² | 160000dots/m² | 105656dots/m² |
| Supporting Hanging | Yes | Yes | Yes | Yes | Yes | Yes |
| Viewing Distance | ≥3-40m | ≥3-40m | ≥3-40m | ≥3-40m | ≥3-40m | ≥3-40m |
| Viewing Angle | X:140° / Y:140° | X:140° / Y:140° | X:140° / Y:140° | X:140° / Y:140° | X:140° / Y:140° | X:120° / Y:120° |
| Max Module Power | 22W | 22W | 22W | 22W | 22W | 22W |
| Max Power Consumption | ≤633W/m² | ≤598W/m² | ≤496W/m² | ≤480W/m² | ≤430W/m² | ≤410W/m² |
| Avg Power Consumption | ≤180W/m² | ≤175W/m² | ≤160W/m² | ≤160W/m² | ≤130W/m² | ≤120W/m² |
| Power Quantity | 200W / 4 Modules | 200W / 4 Modules | 200W / 6 Modules | 200W / 6 Modules | 200W / 6 Modules | 200W / 8 Modules |
| Color Grade | >16.7M | >16.7M | >16.7M | >16.7M | >16.7M | >16.7M |
| Gray Scale | 14bits | 14bits | 14bits | 14bits | 14bits | 14bits |
| Refresh Rate | 3840Hz | 3840Hz | 3840Hz | 3840Hz | 3840Hz | 3840Hz |
| Brightness | 500-600cd/m² | 500-600cd/m² | 500-600cd/m² | 500-600cd/m² | 500-600cd/m² | 500-600cd/m² |
Perfect for:
🎤 Concerts & Festivals
🏢 Corporate Events & Trade Shows
🛒 Retail & Showroom Displays
🎥 Film & TV Production
🏟️ Sports Events & Arenas
